  • Writer's pictureJānis Orlovs

Distributed Tracing with Kuma Service Mesh, Loki, Open Telemetry Collector (OTEL) and Tempo

For the platform engineering team providing self-service and single-pane of glass solutions is the ultimate goal. The article shows how to build an integrated solution for obtaining logs and traces with Kuma service mesh, Grafana, OTEL, and Tempo on top of the Kubernetes cluster.


General Overview


Setup


All are being deployed on GKE for the sake of simplicity.

0. Install GKE Cluster


gcloud container clusters create sample-cluster \     --release-channel stable \     --zone europe-west4-a \     --node-locations europe-west4-a

Don't forget to change the Kubernetes context before moving further Tracing Setup

1. Add helm repos

helm repo add grafana https://grafana.github.io/helm-charts


2. Setup tracing namespace


kubectl apply -f tracing.yaml

tracing.yaml

---
apiVersion: v1
kind: Namespace
metadata:
  name: tracing
  annotations:
    kuma.io/sidecar-injection: "false"

3. Install LOKI


helm install loki grafana/loki -f loki.yaml

loki.yaml

---
fluent-bit:
  enabled: false
promtail:
  enabled: true
prometheus:
  enabled: true
  alertmanager:
    persistentVolume:
      enabled: false
  server:
    persistentVolume:
      enabled: false


3. Install Grafana


helm install grafana grafana/grafana -n tracing --version 6.13.5  -f grafana.yaml

grafana.yaml


---
datasources:
  datasources.yaml:
    apiVersion: 1
    datasources:
      - name: Tempo
        type: tempo
        access: browser
        orgId: 1
        uid: tempo
        url: http://tempo.tracing.svc:3100
        isDefault: true
        editable: true
      - name: Loki
        type: loki
        access: browser
        orgId: 1
        uid: loki
        url: http://loki.kuma-logging.svc:3100
        isDefault: false
        editable: true
        jsonData:
          derivedFields:
            - datasourceName: Tempo
              matcherRegex: "TraceId: (\w+)"
              name: TraceID
              url: "${__value.raw}"
              datasourceUid: tempo
env:
  JAEGER_AGENT_PORT: 6831
adminUser: admin
adminPassword: password
service:
  type: LoadBalancer

4. Install Tempo


helm install tempo grafana/tempo --version 0.7.4 -n tracing -f  tempo.yaml

tempo.yaml


tempo:
  extraArgs:
    "distributor.log-received-traces": true
  receivers:
    zipkin:
    otlp:
      protocols:
        http:
        grpc:


5. Install Open Telemetry Collector

kubectl apply -f  otel.yaml

otel.yaml


---
apiVersion: v1
kind: Service
metadata:
  name: otel-collector
  labels:
    app: opentelemetry
    component: otel-collector
spec:
  ports:
    - name: otlp # Default endpoint for OpenTelemetry receiver.
      port: 55680
      protocol: TCP
      targetPort: 55680
    - name: jaeger-grpc # Default endpoint for Jaeger gRPC receiver
      port: 14250
    - name: jaeger-thrift-http # Default endpoint for Jaeger HTTP receiver.
      port: 14268
    - name: zipkin # Default endpoint for Zipkin receiver.
      port: 9411
    - name: metrics # Default endpoint for querying metrics.
      port: 8888
    - name: prometheus # prometheus exporter
      port: 8889

  selector:
    component: otel-collector
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: otel-collector
  labels:
    app: opentelemetry
    component: otel-collector
spec:
  selector:
    matchLabels:
      app: opentelemetry
      component: otel-collector
  template:
    metadata:
      labels:
        app: opentelemetry
        component: otel-collector
    spec:
      containers:
        - command:
            - "/otelcontribcol"
            - "--config=/conf/otel-collector-config.yaml"
            #           Memory Ballast size should be max 1/3 to 1/2 of memory.
            - "--mem-ballast-size-mib=683"
            - "--log-level=DEBUG"
          image: otel/opentelemetry-collector-contrib:0.29.0
          name: otel-collector
          ports:
            - containerPort: 55679 # Default endpoint for ZPages.
            - containerPort: 55680 # Default endpoint for OpenTelemetry receiver.
            - containerPort: 14250 # Default endpoint for Jaeger HTTP receiver.
            - containerPort: 14268 # Default endpoint for Jaeger HTTP receiver.
            - containerPort: 9411 # Default endpoint for Zipkin receiver.
            - containerPort: 8888  # Default endpoint for querying metrics.
            - containerPort: 8889  # prometheus exporter
          volumeMounts:
            - name: otel-collector-config-vol
              mountPath: /conf
          # livenessProbe:
          #   httpGet:
          #     path: /
          #     port: 13133 # Health Check extension default port.
          # readinessProbe:
          #   httpGet:
          #     path: /
          #     port: 13133 # Health Check extension default port.
      volumes:
        - configMap:
            name: otel-collector-conf
            items:
              - key: otel-collector-config
                path: otel-collector-config.yaml
          name: otel-collector-config-vol
---
apiVersion: v1
kind: ConfigMap
metadata:
  namespace: tracing
  name: otel-collector-conf
  labels:
    app: opentelemetry
    component: otel-collector-conf
data:
  otel-collector-config: |
    receivers:
      zipkin:
        endpoint: 0.0.0.0:9411
    exporters:
      logging:
        loglevel: debug
      otlp:
        endpoint: tempo.tracing.svc.cluster.local:55680
        insecure: true
    service:
      pipelines:
        traces:
          receivers: [zipkin]
          exporters: [otlp]

6. Install KUMA


curl -L https://kuma.io/installer.sh | sh -
./kumactl install control-plane | kubectl apply -f -


7. Enable logging on KUMA


kumactl install logging | kubectl apply -f -

8. Enable KUMA log collector collectors


kubectl apply -f kuma-collector.yaml

kuma-collector.yaml


---
apiVersion: kuma.io/v1alpha1
kind: Mesh
metadata:
  name: default
spec:
  logging:
    defaultBackend: loki
    backends:
      - name: loki
        type: file
        conf:
          path: /dev/stdout
  tracing:
    defaultBackend: zipkin-collector
    backends:
      - name: zipkin-collector
        type: zipkin
        sampling: 100.0
        conf:
          url: http://otel-collector.tracing:9411/api/v2/spans
      - name: jaeger-collector
        type: zipkin
        sampling: 100.0
        conf:
          url: http://jaeger-collector.kuma-tracing:9411/api/v2/spans
---
apiVersion: kuma.io/v1alpha1
kind: TrafficTrace
mesh: default
metadata:
  name: trace-all-traffic
spec:
  selectors:
    - match:
        kuma.io/service: '*'
  conf:
    backend: zipkin-collector
---
apiVersion: kuma.io/v1alpha1
kind: TrafficLog
metadata:
  name: all-traffic
mesh: default
spec:
  # This TrafficLog policy applies all traffic in that Mesh.
  sources:
    - match:
        kuma.io/service: '*'
  destinations:
    - match:
        kuma.io/service: '*'
  # When `backend ` field is omitted, the logs will be forwarded into the `defaultBackend` of that Mesh.


Sample App Install

  1. Install Kong

kubectl apply -f https://bit.ly/k4k8s  kubectl annotate ns kong kuma.io/sidecar-injection=enabled kubectl delete pod --all -n kong


  1. Install book info sample app


kubectl apply -f yamls/7-ns.yaml kubectl apply -f bookinfo.yaml

bookinfo.yaml

---
apiVersion: v1
kind: Service
metadata:
  name: details
  namespace: bookinfo1
  labels:
    app: details
    service: details
  annotations:
    9080.service.kuma.io/protocol: http
    ingress.kubernetes.io/service-upstream: "true"
spec:
  ports:
    - port: 9080
      name: http
  selector:
    app: details
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: bookinfo-details
  namespace: bookinfo1

  labels:
    account: details
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: details-v1
  namespace: bookinfo1
  labels:
    app: details
    version: v1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: details
      version: v1
  template:
    metadata:
      labels:
        app: details
        version: v1
    spec:
      serviceAccountName: bookinfo-details
      containers:
        - name: details
          image: docker.io/istio/examples-bookinfo-details-v1:1.16.2
          imagePullPolicy: IfNotPresent
          ports:
            - containerPort: 9080
          securityContext:
            runAsUser: 1000
---
apiVersion: v1
kind: Service
metadata:
  name: ratings
  namespace: bookinfo1
  labels:
    app: ratings
    service: ratings
  annotations:
    9080.service.kuma.io/protocol: http
    ingress.kubernetes.io/service-upstream: "true"
spec:
  ports:
    - port: 9080
      name: http
  selector:
    app: ratings
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: bookinfo-ratings
  namespace: bookinfo1
  labels:
    account: ratings
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: ratings-v1
  namespace: bookinfo1
  labels:
    app: ratings
    version: v1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: ratings
      version: v1
  template:
    metadata:
      labels:
        app: ratings
        version: v1
    spec:
      serviceAccountName: bookinfo-ratings
      containers:
        - name: ratings
          image: docker.io/istio/examples-bookinfo-ratings-v1:1.16.2
          imagePullPolicy: IfNotPresent
          ports:
            - containerPort: 9080
          securityContext:
            runAsUser: 1000
---
##################################################################################################
# Reviews service
##################################################################################################
apiVersion: v1
kind: Service
metadata:
  name: reviews
  namespace: bookinfo1
  labels:
    app: reviews
    service: reviews
  annotations:
    9080.service.kuma.io/protocol: http
    ingress.kubernetes.io/service-upstream: "true"
spec:
  ports:
    - port: 9080
      name: http
  selector:
    app: reviews
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: bookinfo-reviews
  namespace: bookinfo1
  labels:
    account: reviews
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: reviews-v1
  namespace: bookinfo1
  labels:
    app: reviews
    version: v1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: reviews
      version: v1
  template:
    metadata:
      labels:
        app: reviews
        version: v1
    spec:
      serviceAccountName: bookinfo-reviews
      containers:
        - name: reviews
          image: docker.io/istio/examples-bookinfo-reviews-v1:1.16.2
          imagePullPolicy: IfNotPresent
          env:
            - name: LOG_DIR
              value: "/tmp/logs"
          ports:
            - containerPort: 9080
          volumeMounts:
            - name: tmp
              mountPath: /tmp
            - name: wlp-output
              mountPath: /opt/ibm/wlp/output
          securityContext:
            runAsUser: 1000
      volumes:
        - name: wlp-output
          emptyDir: {}
        - name: tmp
          emptyDir: {}
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: reviews-v2
  namespace: bookinfo1
  labels:
    app: reviews
    version: v2
spec:
  replicas: 1
  selector:
    matchLabels:
      app: reviews
      version: v2
  template:
    metadata:
      labels:
        app: reviews
        version: v2
    spec:
      serviceAccountName: bookinfo-reviews
      containers:
        - name: reviews
          image: docker.io/istio/examples-bookinfo-reviews-v2:1.16.2
          imagePullPolicy: IfNotPresent
          env:
            - name: LOG_DIR
              value: "/tmp/logs"
          ports:
            - containerPort: 9080
          volumeMounts:
            - name: tmp
              mountPath: /tmp
            - name: wlp-output
              mountPath: /opt/ibm/wlp/output
          securityContext:
            runAsUser: 1000
      volumes:
        - name: wlp-output
          emptyDir: {}
        - name: tmp
          emptyDir: {}
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: reviews-v3
  namespace: bookinfo1
  labels:
    app: reviews
    version: v3
spec:
  replicas: 1
  selector:
    matchLabels:
      app: reviews
      version: v3
  template:
    metadata:
      labels:
        app: reviews
        version: v3
    spec:
      serviceAccountName: bookinfo-reviews
      containers:
        - name: reviews
          image: docker.io/istio/examples-bookinfo-reviews-v3:1.16.2
          imagePullPolicy: IfNotPresent
          env:
            - name: LOG_DIR
              value: "/tmp/logs"
          ports:
            - containerPort: 9080
          volumeMounts:
            - name: tmp
              mountPath: /tmp
            - name: wlp-output
              mountPath: /opt/ibm/wlp/output
          securityContext:
            runAsUser: 1000
      volumes:
        - name: wlp-output
          emptyDir: {}
        - name: tmp
          emptyDir: {}
---
##################################################################################################
# Productpage services
##################################################################################################
apiVersion: v1
kind: Service
metadata:
  name: productpage
  namespace: bookinfo1
  labels:
    app: productpage
    service: productpage
  annotations:
    9080.service.kuma.io/protocol: http
    ingress.kubernetes.io/service-upstream: "true"
spec:
  ports:
    - port: 9080
      name: http
  selector:
    app: productpage
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: bookinfo-productpage
  namespace: bookinfo1
  labels:
    account: productpage
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: productpage-v1
  namespace: bookinfo1
  labels:
    app: productpage
    version: v1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: productpage
      version: v1
  template:
    metadata:
      labels:
        app: productpage
        version: v1
    spec:
      serviceAccountName: bookinfo-productpage
      containers:
        - name: productpage
          image: docker.io/istio/examples-bookinfo-productpage-v1:1.16.2
          imagePullPolicy: IfNotPresent
          ports:
            - containerPort: 9080
          volumeMounts:
            - name: tmp
              mountPath: /tmp
          securityContext:
            runAsUser: 1000
      volumes:
        - name: tmp
          emptyDir: {}
---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: demo-ingress
  namespace: bookinfo1
  annotations:
    kubernetes.io/ingress.class: kong
    konghq.com/strip-path: 'true'
spec:
  rules:
    - http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: productpage
                port:
                  number: 9080

Accessing Solution



kubectl port-forward svc/kuma-control-plane -n kuma-system 5681:5681
kubectl port-forward svc/grafana -n tracing 8081:80
To Bookinfo: find ingress and access public IP

Searching in Loki



{namespace="bookinfo"} |="TraceId"


Screens


Trace correlation



14 views0 comments

Recent Posts

See All

At CWISE we believe that log management is one of the most important items when it comes to observability in the company. Options to choose from in operational log analytics are pretty limited in DevO

bottom of page
